100ton Removable Gooseneck Trailer for Sale in Nigeria
A customer from Nigeria customized an 100 ton removable gooseneck trailer. This client is relatively young. He used to work in transportation and was later in charge of import and export business in a company. This time the customer is importing semi-trailers for the company. Since the client is a foreign trade company, he also has a certain understanding of foreign brands. The customer first contacted our online customer service after browsing the product on the website, and then the customer service inquired about the customer's email address and whatsapp. Our sales first learned about their purchase intentions with customers on whatsapp, and learned that customers wanted to buy 100 ton removable gooseneck trailer. Sales sent the quotation to the customer’s mailbox. After a period of negotiation and conversation, the customer finally placed the order. Because the products are customized, our sales are also keeping in touch with customers during the factory production period, and the production progress is also being reported to customers in time. First, the 100 ton removable gooseneck trailer will be shipped soon.
100ton Removable Gooseneck Trailer for Sale in Nigeria
The removable gooseneck semi trailer is a simplified lowbed trailer type for commercial usage.
Despite being of great use in solving many sophisticated issues, the previous gooseneck trailer designs still had issues with the connecting assembly that was found to be complex.
As a result, the removable gooseneck semi trailer was designed to save space and make use of lighter units through a hinged frame assembly.
In more detailed terms, the removable gooseneck semi trailer offers a hinged frame assembly that connects a lowbed trailer type to a tractor.
This assembly is simple in construction and more than that, it is lighter in weight and more compact than other assemblies of this type used for similar applications.
The design is meant to provide a hinged frame assembly as shown in figure 1 above. that has a draft member in one end connected to a pivot-able fifth wheel of a tractor
The other end has a base member pivot-ably linked, so that the actuation of an actuator linked between the base member and the draft member at a point on the base member above the first point, causes the raising or lowering of the front end of a low-bed trailer usually attached to the base member bottom.
100ton Removable Gooseneck Trailer for Sale in Nigeria
1. Strong carrying capacity
Most of this type of removable gooseneck trailer has large tonnage, so the body is mostly designed with an arched cargo bed, and the longitudinal beams are mostly multi-longitudinal high-strength steel structures, which reduces the weight and improves the carrying capacity.
Lowboy trailer's main beam of Shiyun is made of HG60 high-strength structural steel. The yield strength of HG60 steel is ≥ 620MPa, which is more durable and stronger than ordinary steel. Its bearing capacity is 5 times of that of Q345 steel trailer. Shiyun removable gooseneck semi trailer adopts reinforced the gooseneck and upper and lower plate by double layer.
2. Low center of gravity and good stability.
Due to the low ground clearance and low longitudinal beam height of this kind of removable gooseneck semi trailer, the load-bearing surface is 300-400mm lower than that of the normal concave-center removable lowboy semi-trailer, thereby effectively reducing the height of the center of gravity of the loaded goods and improving the stability during transportation.
Oilfield trailers bottom plate, Other suppliers usually use 3 or 4 mm bottom plate, But Shiyun adopt 5 mm thick bottom plate, It’s more durable and won’t be deformed.
100ton Removable Gooseneck Trailer for Sale in Nigeria
3. Good performance
The cargo bed load-bearing surface of the removable gooseneck semi trailer can be adjusted to the ground height by a hydraulic device as needed, and when it passes through culverts or bumpy roads, the cargo bed load-bearing surface can be lowered or raised to improve its passing performance.
4. The effective length of the cargo bed is long
Because this type of model eliminates the rear ladder, the bearing surface can be lengthened, and because the construction machinery does not go from the rear, the slope angle in front of the bridge can be appropriately increased, so that the bearing surface can be lengthened. The length of the low flat cargo table with a ladder at the end is longer, which can effectively load more loads, indirectly improve the loading efficiency, and create greater benefits for users.
5. Easy maintenance
Because the bearing surface can be raised and lowered, the tires on a bridge can be grounded, and other tires can be safely and conveniently replaced or other maintenance work without detaching.
